Designed to produce high pressure air. It is used to start diesel engines with a capacity of up to 500 liters. with. On the Ships[edit] The drive of the compressor K2-150 is carried out through a belt transmission from the internal combustion engine or from an el. Engine. Compressors are equipped with an instrument shield and an oil separator installed outside the compressor. Compressor type - vertical, single-row, three-stage, with differential piston . Refrigeration flowing fresh or sea water. Lubrication Spraying. Compressor control manual. Execution - marine, operation in rooms with artificially controlled climatic conditions at ambient temperature from 50 C to 400 C . Performance (compressed air), l/min 1,8. Pressure final nominal, MPa 15. Compressors can be supplied at a final pressure of 20 MPa, while performance, l/min. 1.33. Power consumption, k. W 7.5. Continuous operation time, not more, min 30. Weight, not more than, kg 82. Overall dimensions, mm 441. 435. 580. Double Pages.
